  ICON DSB




 series DSB RF coaxial connectors is mainly used in series D-SUB connector mix assembled in high/low frequency, and is suitable to assemble with 3~5mm flexible cable.

Key performance

Material

Characteristic Impedance : 50Ω
Frequency range： 0~1GHz
Contact resistance ：
Center conductor：≤6.0mΩ
Out conductor ≤ 2.0mΩ
Insulation resistance : ≥500MΩ
Insulator voltage withstanding： 500V
VSWR：≤1.3
Connector durability：500

Center contacts：
Male---brass, gold plated
Female---beryllium copper, gold plated
Bodies and other metal parts：
brass, gold plated
Insulators:TFE

Applicable spec/std： GJB681A(MIL-C-24308 ) DIN 41612

Products Series:

DSB-UCL/JWB3                   DSB-UCL/J3

DSB-UCL/JW3A                     DSB-UCL/K3Y  DSB-UCL/K3YA

DSB-UCL/JWHD                      DSB-UCL/KWHD

DSB-UCL/KK
