Key performance

Material

Characteristic Impedance ： 50Ω
Frequency range： 0~1GHz
Contact resistance：
Center conductor ：≤6.0mΩ
Out conductor：≤2.0mΩ
Insulation resistance： ≥500MΩ
Insulator voltage withstanding ： 500V
VSWR：≤1.3
Connector durability：500

Center contacts: ：
Male---brass, gold plated
Female---beryllium copper, gold plated
Bodies and other metal parts：
brass, gold plated
Insulators:TFE
Crimp ferrule: copper, nickel plated
Gasket and seal rings: silicone rubber
