  ICON D4




 series D4 RF coaxial connectors is mainly used in series D-SUB connector mix assembled in high/low frequency, and is suitable to assemble with 3~5mm flexible cable.

Key performance

Material

Characteristic Impedance: 50Ω
Frequency range: 0~1GHz
Contact resistance:
Center conductor:≤6.0mΩ
Out conductor:≤2.0mΩ
Insulation resistance : ≥500MΩ
Insulator voltage withstanding: 500V
VSWR :≤1.3
Connector durability:500

Center contacts:
Male---brass, gold plated.
Female---beryllium copper, gold plated
Bodies and other metal parts:
brass, gold plated
Insulators:TFE

                         Applicable spec/std : MIL-C-24308

Products Series:

D4-UCL/JB3                                 D4-UCL/J2.5DF

D4-UCL/J3                                    D4-UCL/J3A

D4-UCL/J223F                                 D4-UCL/K3Y

D4-UCL/K223H                                 D4-UCL/KK
