Characteristic impedance： 75Ω
Ferquency range： 0~1GHz
Contact resistance：
Center conductor≤6.0mΩ
out conductor≤2.0mΩ
Insulation resistance： ≥500MΩ
Insulator voltage withstanding： 500V
Connector durability：500 |
Center contacts：
Male---brass，gold plated
Female---beryllium copper，gold plated
Bodies other metal parts：
brass，gold plated
Insulators：TFE |
DSA-UCL/J3
DSA-UCL/K3Y
DSA-UCL/JWHD
DSA-UCL/KWHD
