  ICON SMB-75




  SERIES SMB-75 RF COAXIAL CONNECTORS

Key performance

Material

Characteristic impedance: 75Ω
Ferquency range: 0~2GHz
Contact resistance:
Center conductor≤6.0mΩ
out conductor≤1.0mΩ
Insulation resistance: ≥1000MΩ
Insulator voltage withstanding: 750V
Connector durability:500

Center contacts:
Male---brass,gold plated
Female---beryllium copper,nickel plated
Bodies other metal parts:
brass,gold plated
Insulators:TFE
Crimp ferrule:brass,nickel plated
Gasket and seal rings:silicone rubber

Applicable spec/std: GJB681A(MIL-C-39012)

Products Series:

SMB-UCL/75JHD                          SMB-UCL/775JWHD

SMB-UCL/75JWHD1                     SMB-UCL/75KHD

SMB-UCL/75KWHD                    SMB-UCL/75KWHDA

SMB-UCL/75J2.5C SMB-UCL/75J4  SMB-UCL/75JW3

SMB-UCL/75JW12                          SMB-UCL/75K3 SMB-UCL/75K3A

SMB-UCL/75K2.5C SMB-UCL/75K4D SMB-UCL/75KW3

SMB-UCL/75KW13                         SMB-UCL/75JYHD

SMB-UCL/75JYHD1                          SMB-UCL/75JYWHD

SMB-UCL/75JYWHD1                       SMB-UCL/75JY

SMB-UCL/75JFD                             SMB-UCL/75JJY
