series SMZ-75 is push-pull self-latching style RF coaxial connector, it is connection convenience and reliable connection, mainly used in ,and wildly used in communication base.
|
Key performance |
Material |
|
Characteristic impedance： 75Ω
Ferquency range： 0~1GHz
Contact resistance：
Center conductor≤6.0mΩ
out conductor≤2.0mΩ
Insulation resistance： ≥1000MΩ
Insulator voltage withstanding： 750V
Connector durability：500 |
Center contacts：
Male---brass，gold plated
Female---beryllium copper，gold plated
Bodies other metal parts：
brass，gold platedornickel plated
Insulators：TFE
Crimp ferrule：brass，nickel plated
Gasket and seal rings：silicone rubber |
Applicable spec/std： BS 9210 |
|
SMZ-UCL/75K3A
SMZ-UCL/75K4 SMZ-UCL/75K4A
SMZ-UCL/75JJ
SMZ-UCL/75KWWK
SMZ-UCL/75KJKR
