Model UCL-BRF860-870
860-870MHZ SMA-K
BANDREJECT FILTER
SPECIFICATIONS
REJECT BAND:860-870MHZ
REJECT ATTENUATION:50DB MIN
PASSBANDS:DC-850MHZ&880-3000MHZ
PASSBAND VSWR:1.6 MAX
PASSBAND LOSS:2DB MAX
IMPEDANCE:50 OHMS
CONNECTORS:SMA-K
SURFACE COLOR:BLACK  UCL-BRF860-870.pdf
|
