Characteristic impedance： 50Ω
Ferquency range： With flexible cable 0~12.4GHz
With semi-rigid/comfortable cable0~18GHz
Contact resistance：
Center conductor≤4.0mΩ
out conductor≤2.0mΩ
Insulation resistance： ≥500MΩ
Insulator voltage withstanding： 1000V
VSWR：with fiexiable cable ≤1.15+0.02f
with semi-rigid/flexiable cable ≤1.10+0.01f
Connector durability：500 |
Center contacts：
Male---brass，gold plated
Female---beryllium copper，gold plated
Bodies other metal parts：
brass，gold plated、nickel plated
stainless steel，passivationorgold plated
Insulators：TFE
Crimp ferrule：brass，nickel plated
Gasket and seal rings：silicone rubber |
